Product Description

Epoxy resin No.: 2120A/B-1
Epoxy resin Specification: 15kg/set

[Main Component of epoxy resin]
A component is resin, B component is curing agent.
The main agent 2120A-1 Curing agent 2120B-1
Color: Colorless transparent Colorless transparent
Specific gravity: 1.15 0.96
Viscosity25° C: 6000-10000CPS 250MAXCPS

[Feature]
Epoxy resin 2120AB-1 is based on the room temperature, having the features of:
(1) high hardness, perfect anti-yellowing
(2) low viscosity, fine natural defoaming performance
(3) high transparency, good ultraviolet light resistance

[Scope Of Application]
The products of this series are widely used for cover carbon fiber products, surfboard, LED, skis, mould filling, and the insulation of other electronic components, moistureproof, potting, confidential encapsulation, etc...

[Conditions of usage]
1)Mixing ratio: A: B = 100: 50(weight ratio)-->2: 1
2)Hardening conditions: 25° C× 2H to 4H or 55° C× 1.5H (2 g)
3)Usable time: 25° C× 15min (100g)

[Using Method]
1. Working environment: The container of holding glue please keep clean, A and B part should be in accordance with the weight ratio, weigh accurately, mix fully along the container wall by clockwise and use after 3 to 5 minutes.
2. According to the operational time and dosage of mixing rubber, avoid wasting. When the temperature below 15° C, please put A glue to glue again after warm up to 30° C, easy to operate, (a glue will be thicken when low temperature ); Must be sealed lid after use, avoid product rejection caused by moisture absorption.
3. When the relative humidity is more than 85%, the curing surface easy to absorb moisture in the air, form a layer of white mist, so when the relative humidity is more than 85%, is not suitable for room temperature curing, suggest to use the heat curing.

[Warning]
1. The operating environment should be ventilative and should keep away of the fire. Closely sealed after use.
2. Avoid the glue contact the skin and the eye, if contacts the skin, with soap and clear water cleaning, if touches the eye carelessly, uses the clear water to flush and to see a doctor immediately.
3. If the liquid cement has the stratification when used for a long time, use after the agitation evenly, do not affect its product quality
4. Take strict precautions against touching by the kids and entering into the mouth.
5. Please make a trial to avoid usage mistakes before application.

[Storage And Packing]
Stock the products in the air-tight seal at the temperature of 25° C. The shelf life is half a year. It is available to use based on passing of the test if being beyond the shelf life.

The properties after hardening
1) Hardness	shore D	<90
2) Withstand voltage	KV/mm	22
3) Flexural strength	Kg/mm2	25
4) Volume resistivity	Ohm3	1x1015
5) Surface resistance	Ohmm2	5X1015
6)Thermal conductivity	W/M.K	0.59
7)Induced electric loss	1KHZ	0.42
8)Withstand high temperature	°C	140
9) Moisture absorption	%	<0.15
10)Compressive strength	Kg/mm2	11.4

FREE SAMPLE IS AVAILABLE!!!
This model canbe widely used for carbon fiber, fiberglass such composite materials coating, it is polishable, with shinning, glossy surface, 2120AB-1 gained high reputation from our customers.Please contact us at discuss your application or for more information.
